Top & Bottom Panels: 8mm thick Side Panels: 4mm thick Front & Rear Panels: 12mm thick
The chassis frame is constructed from 6061 T651 aluminum plate, precision-machined using 3-axis and 4-axis CNC equipment, followed by surface finishing and anodization.
Main frame thickness: 8~12mm; side frame: 4mm. Side mesh upgraded to Migu 6th-gen mesh: sturdier structure with ultra-fine mesh holes for improved airflow.
Hardware Compatibility
GPU Support: Up to 188mm length (excluding power connector and cable protrusion), 40mm width, 70mm height. Compatible with Gigabyte & ASUS RTX 4060 LP / 5060 LP.
Motherboard Support: Standard 170mm × 170mm Mini-ITX motherboards.
Storage Support: 1 × 7mm 2.5" SATA drive. Note: If a 2.5" drive is installed, the front panel can only fit one 9015 fan + one 9025 fan.
CPU Cooler Height Limit: 80mm
Front Fan Support: Two 9025 fans (only when no 2.5" drive is fitted)
Power Supply Support: Small 1U PSU within 170mm length (modular cable length reference available in online documentation)
